Vacuum Excavation VM4000

Our VM4000 vacuum excavator is designed to handle heavy-duty work for underground service locating and /or pipe maintenance, Soft trenching, Non-Destructive Digging around telecommunications cable, gas pipe, sewer lines, and many more.

This model is the most powerful hydro-vac in the fleet. It can hold 4000 liters of spoil at a time. It features a hydraulic tilting tank with a full opening back door for safer dumping.

No Dig Vacuum Excavation carries out works for the civil construction industry, major utility providers, electrical, communications, and plumbing contractors and local government.

Our VM4000 Vacuum Excavators feature the productive know-how that comes from nearly 20 years of supplying contractors and municipalities with durable, reliable trenchless technology equipment in a large-sized machine purpose-built for vacuum excavation.

POWER PACK ENCLOSURE

  • Diesel Engine
  • Powerful Roots Blower
  • Fully Enclosed Blower Pack
  • Protection from the Elements
  • Quiet blower pack for working in urban areas

FILTRATION WITH CLEANOUT

  • Three Stage Filtration System
  • With Cyclone Separation
  • Washable 5 micron filter element
  • Sight glass on filter housing
  • Ease of service

WATER SYSTEM

  • Water pump uses electric clutch feature
  • Water pump can be disengaged when not in use, allowing pull horsepower to the vacuum system
  • Reduces wear on water pump
  • Set at 3500psi for safe working around existing services.

TANK DUMP SYSTEM

  • Hydraulic cylinder tank lift
  • Able to work on cylinders with tank down
  • Remote tank lift control
  • Ease of Operation
  • Manual door lock

VM4000 Vacuum Excavator

Vacuum System

1200 CFM Blower, c/w-4" diameter hose (15'Hg)

Diesel Engine

64 Hp Kohler KDW2204T

Spoil Tank

4000L Capacity with remote hydraulic tipping

High-Pressure Water System

3500psi 15Lpm

Water Tank

2000L

Retractable Hose Reel15 m
Dry Weight3500 Kg

Optional Extras

Double Jet Digging Wand

6.5 inch / 165 mm hole

Hose extension

10 m

Manual Boom Option

With hydraulic up/down movement
